SMT PCB Stencil Cleaning Pneumatic Washing High Pressure Cleaner for Stencil Printer_Steel Mesh Flash-Jet Scrape Jetting Machine

Introduction

Steel mesh high pressure cleaner of High Pressure Spraying Cleaning has two enclosed cavities, the membrane structure cleaning parts go through the up and down spaying nozzle to remove the dirty, then come to the second cavity, there is hot air generated inside, the machine has feeding rollers to transfer in different working position, the machine is specialized in various kinds of cleaning parts with membrane structure character, the waster water will be cycled and filtered to reduce the water consumption, KEEPLEADRE also can do customized design and make to order complying with required cleaning procedure and cleaning effect under one to one function

Character of  Steel mesh high pressure cleaner of High Pressure Spraying Cleaning

The overall size can be make to order

The spaying water can keep its continuous temperature

Have cycling and filtering system, the water consumption at its lowest

One button operation, Automatic completes the whole cleaning process, Auto add and discharge clean and rinse liquid.

 Integrate the function of cleaning, rinsing and drying ,

 Spray pressure adjustably, cleaning in 720 degree directions no blind angle.

 High loading capacity ,saving labor

High -performance rinsing and liquid circulating filtration system, cleaning spray system in the airtight chamber, and keep the cleaning agent life longer, save cost.

 Equipments running with low energy consumption, low noise, no pollution, energy save and environmental protection, the whole structure with stainless steel.

Model

KLE-2024KW

Spaying power

10kw

Hot air power

12kw

Cycling power

2kw

Whole consumption

24kw

Overall size

3*2*1.4m

Parts max height

100mm

Spaying pressure

5-10kgs

Volt/Freq

380V/50HZ

clean agent

Water-based clean agent

Gross weight

500kgs
