Industrial Ultrasonic Cleaning Machine of Six Tank_Automatic Ultrasonic Cleaning Equipment for Metal Parts Ultrasound Degreasing

Industrial Ultrasonic Cleaning Machine

Industrial Ultrasonic Cleaning Machine

Industrial Ultrasonic Cleaning Machine has 6 tanks: *Sonic Cleaning Tank * Rinsing  Tank  *Drying Tank, With Up & Down Agitation and Filter Circulation

Product description


Mainly introduction of Industrial Ultrasonic Cleaning Machine

Stamping parts ultrasonic cleaning machine is used for small stamping parts in cleaning, which can clean the machining lubrication, dirty of blind holes, grooves and dents, is also can be used in plating factory, which is available for any hardware parts before plating, and electronic parts cleaning, electric parts cleaning, optical parts cleaning, and medical appliance cleaning and etc

Character

Stainless steel structure, good performance of acid and alkali resistance

Cleaning part is transferred by robot arm, automatic and high speed

PLC is easy and visible to operate and reset cleaning program

Rotary cleaning basket to get perfect cleaning effect

Automatic load and unload cleaning parts

Completely closed structure, ensure good working enviroment

With oil-water separator, filter system and cycling system

Cleaning procedure

Send the cleaning parts to working position with trolly

Load the basket with cleaning parts into the first cleaning tank

Transfer basket to second cleaning tank and load new basket

Transfer basket to third rinsing tank and load new basket

Transfer basket to fourth rinsing tank and load new basket

Transfer basket to fifth rinsing tank and load new basket

Transfer basket to sixth drying tank and load new basket

Unload the basket with trolly and load new basket

Mainly parameter

Model

KLE-60144AP

Ultrasonic power

7200w*2

Heating power

4kw*6

Ultrasonic frequency

28khz

Cleaning temperature

30 to 60 degree

Cleaning detergent

3% to 10%

Cleaning time

5 to 8 minutes

Number of cleaning tank

2

Number of rinsing tank

3

Number of drying tank

1

Tank size

1.2m*1.2m*1.4m

Overall size

12m*3m*4m

Industrial Ultrasonic Cleaning Machine is acceptable for Cleaning size, Functional combination, above parameter is just for reference, pls email us for technical confirmation
