Blind Cleaning Ultrasonic Cleaner Machine of Window Blinds_Curtain_Drape_Roller Shutter Washing Bath Dual Tank Ultrasound Washer

Blind Cleaning Ultrasonic Cleaner Machine

Blind Cleaning Ultrasonic Cleaner Machine

Blind Cleaning Ultrasonic Cleaner Machine utilizes high frequency sound waves that create millions of microscopic bubbles that implode upon contact with water, all those implosions create tiny vibrations that power the window blind clean safely, effectively and quality, when combined with warm water and a cleaning solution, Blind Cleaning Ultrasonic Cleaner Machine easily removes dust, dirty grime, nicotine, bacteria, virtually any type of window treatment can be cleaned, such as mini-blinds, micro mini-blinds, silhouettes, luminettes, verticals, honeycombs and Roman shades, considering the enormous investment made in installing expensive window treatments, periodically cleaning the blinds makes sense, it is much more cost-effective to renew rather that replace blinds and window treatments, besides, if you have someone the home or workplace with allergies, asthma or respiration issues, its always best to keep the environment a s dust-free as possible, and we all know that blinds can contribute greatly to that problem, Blind Cleaning Ultrasonic Cleaner Machine can definitely solve sanity problem of window blinds

Machine Description


Blind Cleaning Ultrasonic Cleaner Machine

Cleaning method

Professional ultrasonic cleaning is recommended for several products. In an ultrasonic cleaner, the blinds and shades are placed in a chamber containing a suitable ultrasound conducting fluid. An ultrasound generating transducer is built into the chamber, or may be lowered into the fluid. It is electronically activated to produce ultrasonic waves in the fluid. The main mechanism of cleaning action is by energy released from the creation and collapse of microscopic cavitations bubbles, which break up and lift off dirt and contaminants from the blinds and shades. The higher the frequency, the smaller the nodes between the cavitations points which allows for more precise cleaning.

Why in need of cleaning for your window Treatment

Over the years, dirt, dust, grime, nicotine, smoke, and pet odors can contaminate your window coverings. These contaminants can cause irreparable harm if they are not regularly removed.

Allergies: Eliminate irritants by keeping your window treatments clean. Smoke Build-Up:

Dirt and Grime: Smoke from fire damage and nicotine build-up cause window treatments to discolor and look dingy. Window Treatment surfaces are perfect targets for cooking grease, dust and germs.

Cleaning ranges

Wood blinds, Faux wood blinds, mini blinds, PVC vertical blinds, Aluminum blinds, Plastic blinds, Venetian blinds

Application

The ultrasonic blind cleaner is a dual tank system used to clean all types of blinds as well as other fixtures using sonic energy in a water detergent solution, With Blind Cleaning Ultrasonic Cleaner Machine, you can clean virtually any type of window blind on the market today, such as wood blinds, vinyl blinds, venetian blinds, vertical blinds, silhouettes; micro mini blinds, luminettes, roller shades, pleated shades, fabric blinds, privacy curtains, shades, shutters, curtains, draperies

Mainly parameter

The size of Ultrasonic cleaning tank

Model

KLE-2500-B1

Length

2500mm

width

222mm

depth

530mm

capacity

210 liters

Operation capacity

160 liters

The size of rinse tank

Length

2500mm

width

333mm

depth

530mm

capacity

210 liters

Operation capacity

160 liters

Overall dimension

Length

2650mm

width

600mm

height

1100mm

The mainly parameter of machine

Ultrasonic power

6000W

Heating power

5kw

Net weight

480kgs

Ultrasonic frequency

42khz

The number of vibrator

120 up to 200pcs

Character

Dual Tank System, one is dirty cleaning, the other is rinsing tank/tub

Solid Stainless Steel Construction,

digital Timer, counter, counting down buzzer, separated ultrasonic control

Sweep Frequency, capacity is possible in regulation

Four Castors, Two of them have brake

Valve Outlets separated for two cleaning tank, which is built inside

EMC AND LVD  Tested and Approved

Made of 304 stainless steel, do enforcement by strong square tube

Exterior board is 1.0mm 304 stainless steel.

The ultrasonic and rinse chamber are fabricated from 304 stainless steel and are 2.0mm in thickness

A circuit breaker with a rating of 15 amps is also fitted for circuit protection and personal safety

The mains plug/socket outlet is located at the side of the unit, which allows the operator to remove the connection when the unit needs to be re-located

A double valve drain outlet is located at the opposite end of the unit

the machine has plug in hot air drying gun and drying stand

KEEPLEADER has customized Blind Cleaning Ultrasonic Cleaner Machine, please confirm your preferred features before order

Product uses


Blind Cleaning Ultrasonic Cleaner Machine

 Blind Cleaning Ultrasonic Cleaner Machine adopts ultrasonic wave energy, that can produce tinny bubbles when in contact with water, the bubbles implode during alternation of high pressure,the implosive force vertically travel to immersed window blinds, and penetrate into insurmountable area of blinds, that will remove in minutes smoke stains, dust, grease, finger marks, and other soils  but causing no damage at all to the blinds, the process is called ultrasonic cavitation and because these bubbles penetrate the minutest cracks, they reach ass surface of the blind without having to constantly more and reposition them, other optional features on Blind Cleaning Ultrasonic Cleaner Machine is filtration systems to prolong the life of the cleaning solution and the rinsing solution to avoid second contamination

Technology


How ultrasonic work?
Ultrasonic cleaning uses sound waves that are introduced into the cleaning liquid by means of “transducers” mounted to the cleaning tank, the sound waves travel through the tank and create waves of compression and expansion in the liquid, in the compression wave, the molecules of the cleaning liquid are compressed together tightly, conversely, in the expansion wave, the molecular are pulled apart rapidly, the expansion is so dramatic that the molecules are ripped apart creating microscopic bubbles, even though the bubbles are too tiny to be seen by the naked eyes they contain a partial vacuum during the spit second they exist, as the pressure around the bubbles becomes great, the fluid around the bubble rushes in collapsing the bubble very rapidly
How ultrasonic work in blind cleaning?
Professional ultrasonic cleaning is recommended for several products, in an ultrasonic cleaning machine, the blinds and shades are placed in a chamber containing a suitable ultrasound conduction fluid, an ultrasound generating transducer is built into the chamber, or may be lowered in the fluid, it is electronically activated to produce ultrasonic waves in the fluid, the main mechanism of cleaning action is by energy released from the creation and collapse of microscopic cavitations bubbles, which break up and lift off dirty and contaminants from the blinds and shades, the higher the frequency, the smaller the nodes between the cavitations points which allows for more precise cleaning
Blind Cleaning Ultrasonic Cleaner Machine
Blind Cleaning Ultrasonic Cleaner Machine is the most reliable cleaning solution for versatile window blinds, that is also environmentally friendly, over a period of time dust, grime, bacteria, smoke and pollutants, such as pollen become ingrained in the fabric or on the surface of window blind in residential, commercial, office buildings, schools, hospitals, restaurants and more, cleaning blinds by hand is very time consuming and can be messy, plus, with hand cleaning, you cannot get out embedded germ-causing particles and dust, but, tailored dimension of ultrasonic tank is built specially for cleaning blinds and shades, can clean all the parts of blind at the same time, while reviving the mechanism in the head rail as well as restoring the cords, slats, and tapes as close to new as possible
After-salve service


Blind Cleaning Ultrasonic Cleaner Machine is used to clean the window blinds, an ultra-high frequency is transmitted through heated water containing special cleaning agents, microscopic bubbles grow until they implode and it is the thousands of implosions per second that delivery the deep penetrating cleaning action, by using this process there is not scratch, streaking, smearing or potential damage

After purchasing at KEEPLEADER™ is first step of our after-service, all of machines at KEEPLEADER™ has one year guarantee, we provide free samples for defected parts to do replacement except for human damage, under information for your notice

01: KEEPLEADER™ always posts the new technical file in our homepage that can help our client in new technical information of machines’ design, character, application, operation, maintenance,

and related, KEEPLEADER™ also welcome our clients feed back the machines’ working condition that can get one to one service

02: If the machine you purchased has any defects, please contact sales representative at KEEPLEADER™, we will assign our experienced engineer analyze your case and provide technical support, in case of damaged parts that cannot repair, KEEPLEADER™ will provide a new parts to replace the defect

03: For any replacement and maintenance, KEEPLEADER™ has user manual and training video

04: KEEPLEADER™ can go to oversea for on-site training

05: KEEPLEADER™ can provide electric diagram if in need

Contact Us


Blind Cleaning Ultrasonic Cleaner Machine

Blind Cleaning Ultrasonic Cleaner Machine has been employed in the hard window treatment for decades, ultrasonic cavitation removes dust, dust mites dirt, cigarette smoke residue from slats, strings, and all gear track mechanisms and it used by professional cleaning services and retailers, keepleader, we dedicate specified construction, our ultrasonic cleaning machine for window blinds washing gratifies stipulated configuration and dimension for versatile cleaning scenarios, we also carry optional combinations, such as filter circulation reservoir, high pressure spray cleaning wand, hot air drying gun, water dripping tray, drying rack, floated oil skimmer and other more auxiliary devices, don’t hesitate to consult your concerns with our professional teams to find more what we can do for your individual business
