Filter Bag Making Tube Seam Seal PTFE Bags Hot Air Welding Machine of Liquid Membrane Filtration Sleeve Filters Hot Melt Welders

Hot air welding machine for filter bag

Mainly application

Filter Bag Making Tube Seam Seal PTFE Bags Hot Air Welding Machine is applied for welding the filter bag side by hot air under suitable pressure, the machine is electric heating method and transfer heat to the jointing interface, when the material reach its melting point, under the top and bottom rollers generate the suitable pressure, the overlap or laminated fabric is melting together, at the same time, the traction rollers produce a forwarding force to drive the finished filter bag output in side direction

filter Bag Making Tube Seam Seal PTFE Bags Hot Air Welding Machine is mainly used for filter bag welding, through the replacement of mold can also be applied lace clothes, bed sets, pillow cases, car kits, tents, packing tape, backpacks, travel belt, hand strap, curtains, raincoats , coat, snow suits, toys, gloves, tablecloths, chair covers, quilt, masks, hair ornaments, jewelry, umbrellas, lampshades welding

Mainly parameter

Model

KL-120

Temperature

30~600 degree

application

PE,PP and PPS

Thickness of material

0.5 to 2mm

Maximum heating speed

7-14meters/minute

Sealing width

12mm,14mm,16mm,18mm,20mm,22mm

Diameter of filter bag

12 to 400mm

Overall dimension

1.1*1*1.5m

Net weight

200 KG

Motion control

Motor speed drive

Frequency

220V Single phase

Working pressure

0-5 kg

Maximum output power

1200W

Character

01: Adjustable temperature, width, speed and roll prussure to fit different size material.
02: Hot Air can be controlled within±1 to ensure the welding quality.
03: The upper and lower roller can feed the material synchronously to prevent any malposition of the two layers of cloth

04: Adopt the steelwork and sliding guide rail struction

05: the operation panel has power switch, temp display, control and speed control

06: the heating temp is auto compensation and current temp is displayed

07: the machine is easy operation, compacted design and high efficiency

Notice

MFR: KEEPLEADERTM has modified and designed Filter Bag Making Tube Seam Seal PTFE Bags Hot Air Welding Machine to accommodate our customers’ unique and special requirements, pls contact KEEPLEADERTM for tech assessment
