Wire Tube Rope Cutter Computer Cutting Machine gains the prevalent because of its prominence, such as reliable: from the switch to the protective cover, all designs are based on safety; effectiveness:100~D120 pieces can be cut per minute; accuracy:0.1mm high-efficiency feeding microcomputer program control accuracy up to 0.1mm; simplicity: Chinese or English language version of LCD large screen display operation is clean at a glance, concise and convenient
Product description
Decription | |
Strip Tube Pipe Cutter Computer Cutting Machine NYLON shape cutting machine, tape cutting machine, strip cutting machine, soft tube cutting machine, nylon/fabric/pvc/roll/hot fix tape cutting. | |
Strip Tube Pipe Cutter Computer Cutting Machine has maximum cutting width for each machine, that request the clients to provide us with their maximum width, material and shape in cutting for tech audit | |
character | |
The machine adopts microcomputer numerical control device, easy to operate. Replaced knife to couple with different shape cutting. Cutting width can made-to-order. Set length, set-quantity and set-speed cannot be erased if power is switch on and off | |
Mainly application | |
Strip Tube Pipe Cutter Computer Cutting Machine Applicable to bonding, tape, NYLON and other materials rounded, semi-rounded, sword-shaped, rectangular and other fixed-inch cutting, molding use. | |
parameter | |
Model | KL-250 |
power | 750W |
voltage | 220V Single phase or 110V for USA, Canada |
Net weight | 50kgs |
Overall dimension | 360*460*350mm |
productivity | 120-140pcs/min basing 50mm |
Cutting width | 1 up to 250mm |
Cutting tolerance | 0.05mm |
Cutting precision | 0.1mm |
Cutting material | Heat shrinking tube/flat cable/pvc sleeve/insulation tube/two-side tape/cotton yarn belt/nylon belt/elastic belt/zipper/nylon tape/pvc tape/hot fix tape/insulation paper/plastic film cutting. |
Cutting length | 1-99999mm |
Cutter | Cold, can request hot cutter. |
MFR: KEEPLEADER™ has modified and designed Strip Tube Pipe Cutter Computer Cutting Machine to accommodate our customers’ unique and special requirements, pls contact KEEPLEADER™ for tech assessment with your detailed application.
Detailed iamges
Wire Tube Rope Cutter Computer Cutting Machine employs scissoring blade to cut strip of preset length within top width, that is pioneer table-top cutting solution with salient characters, such as multiple layers of strip can synchronously feed in precision, computer numerical control: a microcomputer control system operates speed, temperature, length and quantities; optional power of driving motor, 300w,200w up to 2000w, and cutting speed of 100~120 cut/min (50mm) there is a dissipation fan for secure, fast dissipation; durable construction: stainless steel construction ensures high quality and durability resistance to corrosion and rust, the grounding plug has a built-in fuse with no-leaking, which will not burn the machine; various application: Wire Tube Rope Cutter Computer Cutting Machine is perfect for cutting tube, cable, tape, sheet, fabric cloth, PVC shrink sleeve, plastic film, satin ribbon, Nylon rope, PP elastic band, zipper, Nylon belt, Polyester, webbing strap, Non-oven, label and other more coming in the market
Product uses.
