Automatic CNC battery spot welding machine

Product description


01: Parameter

Name

Automatic CNC Battery Spot Welding Machine

Model

KLM-500SA

X-axis travel

380mm

Y-axis travel

540mm

Spot welding speed

0.5s / point; 1600pcs / h

Maximum speed of motor drive

1000mm/s

batteries loaded

300pcs (standard 18650 lithium battery)

Program

99

Operating system

PLC

Transmission

Stepper + imported precision linear guide (optional servo + screw)

Power supply

Single-phase  220V ± 10% / 50Hz ± 10%

Power

<500w

Air supply

0.3 ~ 0.4Mpa

Weight

200KG

Dimensions

1000mm*1000mm*1800m

02: Application

Automatic battery pack spot welder is professional welding machine to make battery pack using 18650, 26650 battery cell in automatic loading and unloading, it can weld both sides together at high speed,

03: Features

Automatic Monitoring and welding of one side process

Support Soft start, automatic start and manual start model conversation

It has a false spot welding and out of spot welding alarm function

Groups can be saved programming files

Welding needle replacement forecast reminder

Own welding current monitoring system, real-time monitoring of welding current

 Precision Transistor Power generator

Two poles or 4 poles made as requested

.Auto-checking and alarming of miss welding, false welding weak welding, and over welding

.Built-in PLC, which is visual and touch screen in programming

Automatic alignment and correction

Alarming system can remind working status of auto parts, welding, current, position and etc

Adopting Panasonic Servo system

TBI wire rod and THK Guide (or same grade)

SMC cylinder, solenoid valve and filter

OMRON and Panasonic sensor

National standard Aluminum 5015 and 3061 components

Product uses


Automatic CNC battery spot welding machine
