Plastic High Frequency PVC Blister Welding Machine

Plastic High Frequency PVC Blister Welding Machine

Plastic High Frequency PVC Blister Welding Machine has 5kw~15kw, the welding pressure 0.4~30T, Automatid shuttle at two sides,the material can be PVC,APET, PETG Blister, clamshell or Paper card

Product description


Mainly application

Applied for double sides blister packaging for APET, PETG, GAG, PVC, welding and cutting of soft crease box making, toothbrush blister packaging, mobile clearer, belt, watchband, featured in automatic welding and cutting of blister packaging and paper card.

Character

Wide using in environmental protection plastic packing ,toothbrush packing,

environmental production dress-glue products with APET,PETG,GAG materials,

Equally can process any materials needing welding and cutting simultaneously.

double-way automatic slipway, back-forth or continuous delivering the mould,

Accurate-orientation, error±20um.

Adjustable cutting pressure 1-50 ton, stable and reliable in output, firm in structure.

Adopting high sensitive anti-sparkle device NL5557 to avoid damaging the mould efficiency.

Operation mode: oil pneumatic or pure-pneumatic.

Plastic High Frequency PVC Blister Welding Machine has dual shuttles, automatically and enclosed

Technique specifications

Model

KLR-8000WT

Power

8000W

Voltage

220V/380V   50/60HZ

Frequency

27.12MHZ

Input power

15KVA

Rectifier

SILICON DIODE

Oscillation tube

7T69RB

Max pressure

30T

Gap between electrodes

200MM

active horn

150MM

Size of upper electrode

350*500

Size of lower electrode

350*500

Range of temperature

30~200℃ Adjustable

Welding time

0~10S Adjustable

Productivity

Equal or less 5000times/8h

Net weight

1.6T

Overall dimension

1920*1200*2060

Pls contact KEEPLEADER for more info and tech assistance, for Plastic High Frequency PVC Blister Welding Machine, pls tell your material, size of your packages, sample picture to check welding shape

Product uses


Plastic High Frequency PVC Blister Welding Machine

Clamshell, Blister or paper car packages sealing by Plastic High Frequency PVC Blister Welding Machine, which come with one set of mold complied with your packages

Size


Plastic High Frequency PVC Blister Welding Machine

P.s.: About size is standard for 5kw model, used for PET, or paper card welding and cutting

For "Plastic High Frequency PVC Blister Welding Machine", 5kw, 8kw up to 15kw has different weldin, custom model has different size, which will comply with your product, weilding size, welding pressure and high frequency power must be combined in choosing a correct model, or a customized size


Buying guides


Plastic High Frequency PVC Blister Welding Machine

For "Plastic High Frequency PVC Blister Welding Machine", above a popular types of blister packages, if you cannot find the same, pls advise us your difference for tech evaluation

FAQ


How can I buy good quality High frequency welding machine

Firstly: with on line or email conversation, to check the supplier is professional or not, if the supplier has ever supplied the similar machines to other buyer, will be better, don’t save time on studying, don’t stop asking questions before order, more time and efforts you spend, more you can get on the purchasing

What is the auxiliary equipment for High frequency welding machine?

It need one air compressor and necessary tooling, KEEPLEADER ™ can also make the tooling according to your welding products, the buyer need to provide samples and 3D drawing

I never use High frequency welding machine before, how can I operate it?

For small machine, under 10kw, it is easy, KEEPLEADER ™ will provide user manual and train video, also have on line service to resolve any problem

For big machine, example: 50~100kw, Engineers of KEEPLEADER ™ will come to your country, help to install the machine, and train your workers. Buyer also can come to China 1~2 days for necessary Factory training before shipment
Does KEEPLEADER also makes the tooling?

Yes, KEEPLEADER ™ has tooling department, can do customized, please provide samples and 3D drawing of igs format after order
What information does buyer need to provide in advance?

Please let KEEPLEADER ™ know, 1: material, 2: thickness, 3: size of your products, 4: sample picture, 5: purchasing budget

Does KEEPLEADER has messenger for on line service

Skype: keepleader

Whatsapp:+86 13590415784

How long is the warranty time?

One year

Plastic High Frequency PVC Blister Welding Machine can has customized shuttle

Yes, the machine can have one shuttle, or two shuttles at two side, two shuttles at one side
