Golf Club Cleaners Groove Grips Balls Cleaning Ultrasonic Machine is self service, token/coin operated
Product description
Golf Club Ultrasonic Cleaner | |
Related file of ultrasonic cleaning technology | |
With cavitation effect Ultrasonic cleaning technology is widely used in ultrasonic golf club cleaning, semi-conductor silicon chip cleaning, optical glass cleaning, parts of watch and cock cleaning, jewelry cleaning, polyester filtration core cleaning, widow blind cleaning | |
Mainly introduction | |
Ultrasonic technology has been used for over forty years to clean medical, electronic and other high precision equipment. Ultrasonic produce millions of tiny bubbles in a solution that implode when coming into contact with any surface. This quickly and safely removes any surface contamination. Ultrasonic technology works wonders when cleaning golf clubs as the solution reaches all parts of the club head and grips far quicker and more effectively than any other cleaning method. The Ultrasonic Golf Club Cleaner will clean your club heads and grips in a solution that has no moving parts. Ultrasonic cleaning preserves the life of your golf clubs. Golfers with clean club heads and grips play better golf. This innovative and highly reliable machine has been used over the years by thousands and thousands of satisfied golfers. | |
Character Of ultrasonic golf club cleaner from KEEPLEADER™ | |
Token-operated vending machine for self service; Automatically water discharging and filling Fast heating power to reach requested temperature Better collection of tokens inside the machine Minimum fill line on the inside of the tank Each machine in a separate crate High quality token system Built-in separately exciting Generator Built-in Transducers 304 Non-Magnetic Stainless Steel Built-in Thermostatically controlled Heater Built-in Counter Built-in Time | |
The application of ultrasonic cleaner from KEEPLEADER™ | |
Ultrasonic golf club cleaner mainly used to clean the golf club head, golf club grip, and golf club balls remove the surface contamination within five minutes without polution | |
Parameter of ultrasonic golf cleaning machine from KEEPLEADER™ | |
model | KLE-1012F3 |
Brand | KEEPLEADER™ |
Ultrasonic power | 600W up to 1200w |
Power frequency | 50hz or 60hz under request |
Power voltage | 110v or 220v under request |
Heating power | 2kw or 4kw, under request |
connection | Single phase, two wires |
Ultrasonic frequency | 28khz or 40khz |
Tokens | 100pcs per machine |
Temperature control | 0°C to 100 °C |
Cleaning time | 0°C to 999°C |
Generator power | 600w. |
Generator type | PCB type, with 2pcs power board |
Power of vibrator | 50W or 60w |
The quantity of vibrator | 12pcs or under request |
Interior Tank dimensions | 406*381*305mm or under request |
Exterior tank dimensions | 700*480*700mm or under request |
Capacity | 40L |
Net weight | 100kgs |
Gross weight | 120kgs |
Packages | Wooden case, make of fumigation-free material |
Cleaning step | |
Fill the water to be over the minimum fill line Plug in, connect the power supply Regulate the temperature controller (50°C to 70°C) Regulate the timer controller ( 3 minutes to 5 minutes) Switch on the ultrasonic and heating Put the tokens into the slot of token system | |
Special notice | |
Must be sure of the water is over minimum fill line on the inside of tank when heating The size of cleaning tank is under request, which depends on the where the machine is used, home or club shop or golf course You can decide if cradle in need or not, cradle is convenient to load and unload the golfball. You can choose one circle to clean the golf club heads and golfball, another circle to cleaning golf club grips You can make trolley to let keepleader’s machine sit in for convenient movement, KEEPLEADER™’s machines also have Universal wheel OEM, ODM order is available, we also accept customized design |
MFR: KEEPLEADER™ has modified and designed Golf Club Cleaners Groove Grips Balls Cleaning Ultrasonic Machine to accommodate our customers’ unique and special requirements, pls contact KEEPLEADER™ for updated tech files
After-sales service
After purchasing at KEEPLEADER™ is first step of our after-service, all of machines at KEEPLEADER™ has one year guarantee, we provide free samples for defected parts to do replacement except for human damage, under information for your notice
01: KEEPLEADER™ always posts the new technical file in our homepage that can help our client in new technical information of machines’ design, character, application, operation, maintenance, and related, KEEPLEADER™ also welcome our clients feed back the machines’ working condition that can get one to one service
02: If the machine you purchased has any defects, please contact sales representative at KEEPLEADER™, we will assign our experienced engineer analyze your case and provide technical support, in case of damaged parts that cannot repair, KEEPLEADER™ will provide a new parts to replace the defect
03: For any replacement and maintenance, KEEPLEADER™ has user manual and training video
04: KEEPLEADER™ can go to oversea for on-site training
05: KEEPLEADER™ can provide electric diagram if in need
06: Golf Club Cleaners Groove Grips Balls Cleaning Ultrasonic Machine has user manual and tutorial video
Buying guidesGolf club ultrasonic cleaner is not like most other ultrasonic machines you man see available, KEEPLEADER™ systems are manufactured in China, and are designed specifically to do the job at hand, as well as clean golf clubs, efficiency, safely and effectively, the equipment is also designed for mobile use, so how do ultrasonic work and why is so effective?
What is ultrasonic cleaning?
Ultrasonic or sound waves through water, create a process termed “ cavitations” this is the rapid formation and implosion of millions of tiny bubbles ( or cavities) in a liquid, cavitations is produced by the alternating high and low pressure waves generated by high frequency ultrasonic sound, during the low pressure phase, these bubbles grow from microscopic size until, during the high pressure phase where they are compressed and implode, KEEPLEADER™ system produces 60,000 waves of sound every second, because of the inherently small size of bubble/implosion and the relatively large energy, ultrasonic cleaning has the ability to reach into small crevices and removed soil very effectively
So basically it is not just about cleaning the mud off from that last duff shot, it gives your clubs a deep clean, so you can use the technology of the club as designed
Ultrasonic is used widely throughout industry for removing problem contamination from all kinds of hard surfaces, its unique properties can be harnessed to clean items of all shapes, sizes and technical complexity, penetrating holes and cavities that are impossible to reach using ordinary cleaning methods
There are many considerations important to ultrasonic cleaning and optimizing there variables will produce the best cleaning, the most important decisions to be make are choosing the proper cleaning solution, cleaning at the right temperature for the correct amount of time, and choosing the right size and type of ultrasonic cleaner
KEEPLEADER™ golf club ultrasonic cleaner are set for optimum cleaning of golf clubs, not Jeweler, engine parts or hospital beds, the temperature is pre-set in the system so as not to overheat the non metallic components of the golf club, the volume of the tanks are specifically calculated to maximum the effectiveness of the 12 transducers (that produce sound waves) so that we clean the clubs in the time scale we advertise
KEEPLEADER™ Franchiseespolicy will arrange raining to use the right amount of cleaning solutions, specific to the water composition (soft/hard)of their individual areas, the water is also degassed (so that excess air is driven from the liquid) 24 hours before using, again to maximize the performance
